Fully Automatic Electric Stacker
The BS-ST-108 Fully Automatic Electric Stacker from BAIR SHIFT is designed for efficient pallet handling, vertical stacking and material movement in warehouses, distribution centres and industrial storage facilities. With a rated load capacity of 1.5 tons, it is available in two lifting height variants: 4500 mm and 6000 mm, allowing businesses to select a configuration suited to their warehouse racking requirements. The stacker features a 24V battery system with a listed capacity of 75 Ah and a 1.5 kW drive motor. Its polyurethane (PU) wheel system supports movement on suitable warehouse floors, while its powered drive and lifting functions help reduce the manual effort involved in routine material handling. The listed vehicle length is 263 cm, with fork dimensions of 1150 × 60 mm.
Everything you need to know about this product.
|
Specification |
Details |
|---|---|
|
Product Name |
Fully Automatic Electric Stacker |
|
Model |
BS-ST-108 |
|
Brand |
BAIR SHIFT |
|
Parent Company |
Bharat Air Technologies Pvt. Ltd. |
|
Rated Load Capacity |
1.5 tons (1500 kg) |
|
Available Lifting Heights |
4500 mm and 6000 mm |
|
Drive Motor Power |
1.5 kW |
|
Battery Voltage |
24 V |
|
Battery Capacity |
75 Ah |
|
Wheel Type |
Polyurethane (PU) |
|
Tyre Size |
250 × 80 mm / 80 × 70 mm |
|
Fork Dimensions |
1150 × 60 mm |
|
Front/Rear Wheel Track |
115 mm |
|
Minimum Ground Clearance |
30 mm |
|
Listed Vehicle Length |
263 cm |
The BAIR SHIFT BS-ST-108 Fully Automatic Electric Stacker provides a powered solution for lifting and stacking palletised loads in industrial storage and warehouse environments. Its 1.5-ton rated capacity and two available lifting heights make it suitable for facilities with different storage rack configurations and vertical handling requirements.
Powered by a 24V, 75 Ah battery system and a 1.5 kW drive motor, the stacker is designed to support powered material movement and pallet stacking. The PU wheel system is intended for operation on compatible warehouse floors, while the 1150 × 60 mm forks accommodate suitable pallet-handling tasks.
The 4500 mm and 6000 mm variants allow buyers to choose a lifting height according to their rack height, available aisle space, pallet dimensions and operational requirements. Confirm the load capacity applicable at the required lifting height, aisle-width requirements and battery operating details with the manufacturer before selection.
KEY FEATURES
-
1.5-Ton Load Capacity: Designed for palletised loads up to the rated capacity, subject to the load chart and operating conditions.
-
Two Lifting Height Options: Available in 4500 mm and 6000 mm configurations.
-
Powered Drive: Equipped with a listed 1.5 kW drive motor.
-
Rechargeable Battery System: Uses a 24V battery with a listed capacity of 75 Ah.
-
Polyurethane Wheels: Supports movement across suitable warehouse floors.
-
Practical Fork Dimensions: Listed fork dimensions of 1150 × 60 mm for compatible pallet-handling applications.
APPLICATIONS
-
High-bay warehouses and storage facilities
-
Distribution centres and logistics operations
-
Manufacturing and production facilities
-
Pallet stacking and retrieval
-
Industrial inventory management
-
Warehousing operations requiring elevated pallet storage
|
Specification |
Details |
|---|---|
|
Model |
BS-ST-108 |
|
Rated Load Capacity |
1.5 tons (1500 kg) |
|
Maximum Lifting Height — Type A |
4500 mm |
|
Maximum Lifting Height — Type B |
6000 mm |
|
Drive Motor Power |
1.5 kW |
|
Battery Voltage |
24 V |
|
Battery Capacity |
75 Ah |
|
Wheel Type |
Polyurethane (PU) |
|
Tyre Size |
250 × 80 mm / 80 × 70 mm |
|
Fork Dimensions |
1150 × 60 mm |
|
Front/Rear Wheel Track |
115 mm |
|
Minimum Ground Clearance |
30 mm |
|
Listed Vehicle Length |
263 cm |
